Product Overview
Aptokart Class II B2 Biosafety Cabinets are 100% exhaust cabinets where there is no recirculation within the work area. The room air enters through a blower on the top of the cabinet and passes through a HEPA filter into the work station. as vertical unidirectional airflow. Descending aur is pulled through the base of the cabinet through the perforated front and rear grills. Simultaneously air entering through the perforated front opening is pulled through the grill and exhausted immediately. 100% of the air is pulled into the exhaust system which creates a negative pressure around the work area with double wall plenums for protection. Air drawn through pre-filter is made to pass through highly effective HEPA filters. Supply filters having efficiency rating as high as 99.99% with cold DOP and 99.97% with hot DOP, thus retaining all air-borne particles of size 0.3 micron and larger. the highly efficient HEPA filters maintain the optimum cleanliness and purity. Aerodynamic airflow grills maintain safety and prevents blockage. UV and Fluorescent interlock is available. Ergonomic and comfortable sloped front window for comfortable head and elbow rest position, thus reducing fatigue. Sash is counterbalanced for smooth and light weight operation with standard opening for easier access to work station and enhanced user safety. |
Technical Specifications
MOC | Internal working chamber: SS-304, Exterior cabinet: Cold rolled steel duly powder coated or SS- 304 |
Pre- Filter | Mounted on aluminum frame of rating 20 microns |
Supply/Main Filter | HEPA (Efficiency 99.97% @0.3 microns to meet air quality) |
Exhaust Filter | HEPA (Efficiency 99.97% @0.3 microns to meet air quality) |
Electrical Socket | Electrical socket is provided for using small electrical devices |
Power Supply | 220/230 Volts AC supply |
Any Duty exhaust system | Standard fitted to the system for 100% exhaust |
Any Tunnel /Duct (optional) | Available on per running feet basis |
Sash Lift | Can be lifted and adjusted manually |
Ordering Informations
Model | AK-BSC 02 | AK-BSC 03 | AK-BSC 04 | AK-BSC 05 | AK-BSC 06 |
| 600x600x600 | 900x600x600 | 1200x600x600 | 1500x600x600 | 1780x600x600 |
