Fume Hood (5 Ft)

Model - AMBI-FH-05

Description

Fume Hoods are designed to function as an enclosed ventilated workspace- can provide a substantial degree of protection for the experimenter. It is designed so as to throw-out all toxic harmful vapour, acidic/alkaline fumes, chemical vapors, removal of odour etc from the hood working area, thus protecting costly instruments and the person working in the lab.

Key Features

• LowNoise.
• User Friendly Ergonomic Design.
• Double-walled construction.
• Material : Mild steel powder coated .
• All interior surfaces are sealed and checked for leakage.
• Work table is made of Jet black granite (Thickness : 18 mm).
• Working area is illuminated by fluorescent lighting fitted to the unit.
• The front shutter made of toughened float glass moves vertically up and down with concealed counter balanced weight.
• The centrifugal blower and motor assembly is statically and dynamically balanced & operates with minimum noise level.
• Supplied with bottom storage cabinet.
• Provided with levelling jacks.
• Supplied with cord & plug to work on Single Phase 220 / 230 volts A.C. supply

Technical Specifications

• Overall dimension (mm) (Wx Dx H) - 1800x700x2400
• Inner dimension (mm) (Wx Dx H) - 1500x600x1150
• Application -  Provide protection to the operator
• Control panel -   Separate switch for Fan & Fluorescent Light
• Face Velocity -  80-120 FPM
• Noise level - Less than 70 db
• Illumination - 400 LUX [Fluorescent Light]
• Ducting - PVC (Dia-8”Inches)
• Motor -  Heavy duty single phase
• Nominal voltage - 220-230 Volts,50 Hz Single Phase
• Accessories - Electric socket (5/15 amp) with MCB – 2Nos.
